JCB JS160NLC Hydraulic Excavator
Dimensions
Boom/Stick Option (Hex) 1
Shipping Length Of Unit
27.33ft in
Shipping Height Of Unit
9.75ft in
Max Cutting Height
29.08ft in
Max Loading Height
21.42ft in
Max Reach Along Ground
27.33ft in
Max Vertical Wall Digging Depth
16.08ft in
Max Digging Depth
17.93ft in
Max Digging Reach
27.92ft in
Minimum Swing Radius
118.12in
Boom/Stick Option (Hex) 1
Arm Length 7 ft 5 in(2.25m ), Boom 16 ft 11 in (5.15m )
Max Digging Reach On Ground
27.32ft in
Boom/Stick Option (Hex) 2
Shipping Length Of Unit
27.17ft in
Max Cutting Height
29.67ft in
Shipping Height Of Unit
9.75ft in
Max Loading Height
22.08ft in
Max Reach Along Ground
28.58ft in
Max Vertical Wall Digging Depth
17.36ft in
Max Digging Depth
29.5ft in
Max Digging Reach
29.23ft in
Minimum Swing Radius
118.12in
Boom/Stick Option (Hex) 2
Arm Lenght 8 ft 10 in (2.70m) , Boom 16 ft 11 in (5.15m )
Max Digging Reach On Ground
28.66ft in
Boom/Stick Option (Hex) 3
Shipping Length Of Unit
27.5ft in
Max Cutting Height
30.25ft in
Max Loading Height
22.17ft in
Shipping Height Of Unit
9.75ft in
Max Reach Along Ground
29.67ft in
Max Vertical Wall Digging Depth
18.5ft in
Max Digging Depth
20.58ft in
Minimum Swing Radius
118.12in
Boom/Stick Option (Hex) 3
Arm Length 10 ft 0 in (3.05m ), Boom 16 ft 11 in (5.15m )
Max Digging Reach On Ground
29.72ft in
Max Digging Reach
30.26ft in
Dimensions
Ground Clearance
1.58ft in
Height To Top Of Cab
9.67ft in
Width To Outside Of Tracks
8.17ft in
Length Of Track On Ground
10.17ft in
Tail Swing Radius
7.67ft in
Transport Length
328.27in
Removal Counterweight Clearance
3.42ft in
Transport Height
123.63in
Undercarriage Overall Length
12.93ft in
Undercarriage
Track Gauge
7.22ft in
Shoe Size
23.63in
Ground Pressure
5.83psi
Track Adjustment
Grease cylinder type
Number Of Carrier Rollers Per Side
2
Drawbar Pull
323721lb
Number Of Shoes Per Side
43
Number Of Track Rollers Per Side
7
Max Travel Speed
3.1mph
Specifications
Engine
Battery
2 x 12 V
Number Of Cylinders
4
Engine Make
2353
Engine Model
JCB EcoMAX 444 TCA EU Stage IV, EPA Tier 4 Final compliant
Net Power
124.8hp
Power Measured @
2000rpm
Aspiration
Turbocharged and intercooled
Displacement
183cu in
Alternator
55amps
Capacities
Def Tank
14.3gal
Engine Oil
0.6gal
Engine Coolant
5.3gal
Operational
Operating Weight
37996.7lb
Fuel Capacity
66.8gal
Cooling System Fluid Capacity
4.3gal
Hydraulic System Fluid Capacity
37.5gal
Operating Voltage
24V
Engine Oil Capacity
3.5gal
Swing Drive Fluid Capacity
1.6gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4554psi
Hydraulic Pump Flow Capacity
36.5gal/min
Travel Speed
3.5mph
Swing Mechanism
Swing Gear
Large diameter, internally toothed fully sealed grease bath lubricated
Swing Motor
Axial piston type
Swing Brake
Hydraulic braking plus automatic spring applied disc type parking brake
Swing Speed
10rpm
Swing Torque
2581.5lb ft
Buckets
Reference Bucket Capacity
1.2yd3
Minimum Bucket Capacity
0.5yd3
Maximum Bucket Capacity
1.3yd3
Hydraulic System
Power Boost
23.5psi
Main Pump - Maximum Flow
86.7gal/min
Maximum Flow -Servo Pump, Low Noise Gear Pump
5.5gal/min
Travel Circuit
23.5psi
Swing Circuit
19.3psi
Pilot Circuit
2.8psi
Control Valve
A combined ten spool control valve with auxiliary service spool as standard
Brakes
Parking Brake
Disc type, spring applied, automatic hydraulic release
Service Brake
Hydraulic counter balance valve
Gradeability
70 %
