JCB JS460LC Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
39.08ft in
C
Shipping Height Of Unit
12.58ft in
I
Max Cutting Height
37.92ft in
J
Max Loading Height
27.75ft in
K
Max Reach Along Ground
42.33ft in
L
Max Vertical Wall Digging Depth
24.17ft in
M
Max Digging Depth
29.5ft in
Boom/Stick Option (Hex) 1
Dipper Arm 15ft.6in.(4.76m )
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
38.75ft in
I
Max Cutting Height
36.92ft in
C
Shipping Height Of Unit
11.58ft in
J
Max Loading Height
26.17ft in
K
Max Reach Along Ground
40.25ft in
L
Max Vertical Wall Digging Depth
22.75ft in
M
Max Digging Depth
27.5ft in
Boom/Stick Option (Hex) 2
Dipper Arm 13ft.1in.(4.00m )
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
38.67ft in
I
Max Cutting Height
36.33ft in
J
Max Loading Height
25.58ft in
C
Shipping Height Of Unit
11.42ft in
K
Max Reach Along Ground
38.42ft in
L
Max Vertical Wall Digging Depth
20.83ft in
M
Max Digging Depth
25.33ft in
Boom/Stick Option (Hex) 3
Dipper Arm 11ft 0in.(3.36m )
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
38.75ft in
C
Shipping Height Of Unit
11.5ft in
I
Max Cutting Height
35.5ft in
J
Max Loading Height
24.75ft in
K
Max Reach Along Ground
35.92ft in
M
Max Digging Depth
22.5ft in
Boom/Stick Option (Hex) 4
Dipper Arm 8ft 2in (2.50m )
Max Vertical Wall Dig Depth
18.25ft in
Dimensions
E
Ground Clearance
2ft in
G
Height To Top Of Cab
10.75ft in
B
Width To Outside Of Tracks
11.32ft in
D
Length Of Track On Ground
14.42ft in
H
Tail Swing Radius
11.33ft in
Removal Counterweight Clearance
4.5ft in
Undercarriage
F
Track Gauge
9.17ft in
N
Shoe Size
27.56in
Number Of Carrier Rollers Per Side
9
Max Travel Speed
2.4mph
Ground Pressure
10.52psi
Number Of Track Rollers Per Side
2
Number Of Shoes Per Side
52
Drawbar Pull
85318lb
Specifications
Engine
Number Of Cylinders
6
Engine Make
2353
Engine Model
AA-6SDITC
Net Power
305hp
Power Measured @
2000rpm
Aspiration
Turbocharged
Displacement
600.4cu in
Operational
Operating Weight
100442lb
Fuel Capacity
172gal
Cooling System Fluid Capacity
12.6gal
Hydraulic System Fluid Capacity
119gal
Operating Voltage
24V
Swing Drive Fluid Capacity
2.2gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4712psi
Hydraulic Pump Flow Capacity
90gal/min
Swing Mechanism
Swing Speed
9.2rpm
Buckets
Reference Bucket Capacity
3yd3
Minimum Bucket Capacity
1.9yd3
Maximum Bucket Capacity
3yd3
