JCB MINI CX Loader Backhoe
Units
Dimensions
Backhoe
J
Load Height - Std
6.3ft in
K
Reach From Swivel - Std
12.28ft in
L
Dig Depth - Std
8.34ft in
M
Reach At Load Height - Std
6.65ft in
Dimensions
A
Transport Length
14.87ft in
B
Transport Width
4.83ft in
C
Transport Height
6.98ft in
D
Wheelbase
5.12ft in
Height To Top Of Suspended Cab
6.98ft in
Loader
G
Clearance At Max Dump Height
5.69ft in
H
Reach At Max Dump Height
3.5ft in
I
Dig Depth
2.56in
Lift Capacity At Full Height
3444lb
Bucket Capacity
0.3yd3
Bucket Breakout Force
3607lb
Specifications
Engine
Number Of Cylinders
3
Engine Model
103-10
Net Power
20hp
Gross Power
20.5hp
Power Measured @
2800rpm
Torque Measured @
2800rpm
Net Max Torque
41.5lb ft
Aspiration
Naturally Aspirated
Displacement
58.3cu in
Operational
Operating Weight 2wd
3373lb
Fuel Capacity
7.7gal
Hydraulic System Fluid Capacity
14.1gal
Oil System Fluid Capacity
1gal
Cooling System Fluid Capacity
1gal
Rear Axle Fluid Capacity
0.4gal
Turning Radius
19.2ft in
Tire Size Front - 2wd / 4wd
23x8.5-12
Rear Tires Size 2wd/4wd
400/50-15
Operating Voltage
12V
Alternator Supplied Amperage
40amps
Transmission
Transmission Type
Hydrostatic
Max Speed - Forward
6.2mph
Max Speed Reverse
3.7mph
Hydraulic
Pump Type
fixed displacement pump
Pump Flow Capacity
8.5gal/min
Relief Valve Pressure
2900psi
