JLG 1644 HIGH CAPACITY MODEL Telescopic Forklift
Units
Dimensions
Dimensions
E
Ground Clearance
1.7ft in
C
Overall Height
8.9ft in
D
Wheelbase
10.7ft in
Width
8.1ft in
Overall Length
20.3ft in
Lift
F
Max Lift Height
43ft in
Max Load At Max Reach
31.1lb
Load Center
2ft in
Max Lift Capacity
15650lb
Max Load At Max Height
6750lb
Specifications
Engine
Engine Model
TCD 3.6L Tier 4 Final
Gross Power
134hp
Power Measured @
2200rpm
Capacities
Fuel Tank
39gal
Operational
Drawbar Pull
23000lb
Tire Size
17.5-25 SGG
Performance
Maximum Lift
18.3sec
Maximum Lower
13.6sec
Maximum Telescope In
12.3sec
Maximum Telescope Out
15.8sec
Maximum Travel
20mph
Transmission
Transmission Type
Hydrostatic
Weights
Operating Weight
33660lb
Hydraulic
Pump Type
Load Sensing Piston
Axles
Front
High Bias, Limited Slip
Rear
Oscillating
Brakes
Brakes Type
Wet Multi-Disc
