JLG 260MRT Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
8.9in
D
Wheelbase
6.6ft in
B
Overall Width
5.9ft in
E
Ground Clearance
8in
Overall Height
7.1ft in
Height W/O Rails
7.78ft in
Turning Radius
14.5ft in
Platform
F
Max Platform Height
25.99ft in
I
Deck Extension
48.04in
J
Height Of Rails
3.8ft in
Lift Time
27sec
Max Platform Weight Capacity
1250.03lb
Platform Inner Length
101.97in
Platform Inner Width
64.97in
Platform Railing Height
25.99ft in
Platform Capacity - Extension
300lb
Max Working Height
32ft in
Lower Time
21sec
Specifications
Engine
Fuel Tank
7.5gal
Maximum Ground Bearing Pressure
33psi
Engine Make
2334
Engine Model
Kubota 24.5 hp
Engine Type
Kubota 23.5 hp
Gross Power
24.5hp
Fuel Type
Dual Fuel
Operational
Operating Weight
7360lb
Fuel Capacity
7.5gal
Hydraulic System Fluid Capacity
15gal
Max Speed
3.5mph
Tire Size
26x12
Tire Fill/Type
Lug Tread
Performance
Drive Speed - Platform Elevated
0.5mph
Drive Speed - Platform Lowered
3.5mph
Maximum Drive Height
26ft in
Platform Capacity
1250lb
Brakes
Brakes Type
Spring Applied, Hydraulically Released
