John Deere 135C RTS Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
23.92ft in
C
Shipping Height Of Unit
9.33ft in
I
Max Cutting Height
30.25ft in
J
Max Loading Height
22.18ft in
K
Max Reach Along Ground
26.78ft in
L
Max Vertical Wall Digging Depth
16.31ft in
M
Max Digging Depth
18.15ft in
Boom/Stick Option (Hex) 1
8\'3\" (2520mm) stick
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
24ft in
I
Max Cutting Height
31.53ft in
C
Shipping Height Of Unit
9.33ft in
J
Max Loading Height
23.46ft in
K
Max Reach Along Ground
28.35ft in
L
Max Vertical Wall Digging Depth
17.92ft in
M
Max Digging Depth
19.76ft in
Boom/Stick Option (Hex) 2
9\'11\" (3010mm) stick
Dimensions
E
Ground Clearance
1.45ft in
G
Height To Top Of Cab
8.99ft in
B
Width To Outside Of Tracks
8.83ft in
D
Length Of Track On Ground
9.45ft in
H
Tail Swing Radius
4.81ft in
Removal Counterweight Clearance
2.92ft in
Undercarriage
F
Track Gauge
6.53ft in
N
Shoe Size
27.56in
Number Of Shoes Per Side
44
Drawbar Pull
26300lb
Number Of Track Rollers Per Side
7
Number Of Carrier Rollers Per Side
1
Max Travel Speed
3.11mph
Ground Pressure
5.09psi
Specifications
Engine
Number Of Cylinders
4
Engine Make
2353
Engine Model
CC-4BG1TC
Net Power
88hp
Power Measured @
2150rpm
Max Torque
253lb ft
Displacement
264.2cu in
Aspiration
Turbocharged and air-to-air charge air cooler
Torque Measured @
1600rpm
Operational
Operating Weight
30441.5lb
Fuel Capacity
53.1gal
Cooling System Fluid Capacity
3.8gal
Hydraulic System Fluid Capacity
31.8gal
Operating Voltage
24V
Engine Oil Capacity
3.5gal
Swing Drive Fluid Capacity
0.7gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4980psi
Hydraulic Pump Flow Capacity
55.5gal/min
Swing Mechanism
Swing Speed
13.7rpm
Swing Torque
24387lb ft
Buckets
Reference Bucket Capacity
0.9yd3
Minimum Bucket Capacity
0.5yd3
Maximum Bucket Capacity
1.6yd3
