John Deere 17ZTS Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
12ft in
I
Max Cutting Height
11.58ft in
C
Shipping Height Of Unit
7.62ft in
J
Max Loading Height
8.33ft in
K
Max Reach Along Ground
12.92ft in
M
Max Digging Depth
7.25ft in
Boom/Stick Option (Hex) 1
Arm length 3ft.1in. (930mm)
Dimensions
B
Width To Outside Of Tracks
4.42ft in
D
Length Of Track On Ground
3.97ft in
E
Ground Clearance
0.79ft in
G
Height To Top Of Cab
7.58ft in
H
Tail Swing Radius
2.25ft in
Removal Counterweight Clearance
1.5ft in
Undercarriage
N
Shoe Size
9.06in
Ground Pressure
4.34psi
Max Travel Speed
2.5mph
Specifications
Engine
Engine Make
2353
Engine Model
3YB1
Net Power
12.3hp
Power Measured @
2300rpm
Displacement
46.4cu in
Operational
Operating Weight
3814lb
Fuel Capacity
6.6gal
Hydraulic System Fluid Capacity
7.4gal
Operating Voltage
12V
Alternator Supplied Amperage
35amps
Hydraulic Pump Flow Capacity
7.7gal/min
Swing Mechanism
Swing Speed
8.6rpm
Buckets
Reference Bucket Capacity
0.1yd3
Minimum Bucket Capacity
0.1yd3
Maximum Bucket Capacity
0.1yd3
