John Deere 200C LC Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
31.17ft in
C
Shipping Height Of Unit
9.75ft in
J
Max Loading Height
22.25ft in
K
Max Reach Along Ground
31.99ft in
L
Max Vertical Wall Digging Depth
19.85ft in
M
Max Digging Depth
21.92ft in
Boom/Stick Option (Hex) 1
9\'7\" (2910mm) stick
Dimensions
E
Ground Clearance
1.48ft in
B
Width To Outside Of Tracks
10.5ft in
D
Length Of Track On Ground
12.01ft in
H
Tail Swing Radius
8.99ft in
Undercarriage
F
Track Gauge
7.83ft in
N
Shoe Size
31.89in
Ground Pressure
4.72psi
Drawbar Pull
42420lb
Number Of Carrier Rollers Per Side
2
Number Of Track Rollers Per Side
8
Max Travel Speed
3.42mph
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6068H
Net Power
141hp
Power Measured @
2150rpm
Max Torque
427.1lb ft
Aspiration
Turbocharged
Displacement
414cu in
Torque Measured @
1300rpm
Operational
Operating Weight
46130lb
Fuel Capacity
95.2gal
Hydraulic System Fluid Capacity
34gal
Hydraulic System Relief Valve Pressure
4980psi
Hydraulic Pump Flow Capacity
115.8gal/min
Swing Mechanism
Swing Speed
13.3rpm
Buckets
Reference Bucket Capacity
1.2yd3
Minimum Bucket Capacity
0.8yd3
Maximum Bucket Capacity
2.1yd3
