John Deere 200D LC Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
31.27ft in
C
Shipping Height Of Unit
9.68ft in
I
Max Cutting Height
32.94ft in
J
Max Loading Height
23.56ft in
K
Max Reach Along Ground
31.99ft in
L
Max Vertical Wall Digging Depth
19.66ft in
M
Max Digging Depth
21.92ft in
Boom/Stick Option (Hex) 1
9\'7\" (2910mm) stick
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
31.5ft in
I
Max Cutting Height
31.73ft in
C
Shipping Height Of Unit
10.44ft in
J
Max Loading Height
22.41ft in
K
Max Reach Along Ground
30.35ft in
L
Max Vertical Wall Digging Depth
17.39ft in
M
Max Digging Depth
20.28ft in
Boom/Stick Option (Hex) 2
7\'11\" (2420mm) stick
Dimensions
E
Ground Clearance
1.48ft in
G
Height To Top Of Cab
9.68ft in
B
Width To Outside Of Tracks
10.47ft in
D
Length Of Track On Ground
12.05ft in
H
Tail Swing Radius
9.03ft in
Removal Counterweight Clearance
3.39ft in
Undercarriage
F
Track Gauge
7.83ft in
N
Shoe Size
31.5in
Number Of Shoes Per Side
49
Drawbar Pull
45620lb
Number Of Track Rollers Per Side
8
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.42mph
Ground Pressure
5.3psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6068H
Net Power
159hp
Power Measured @
2000rpm
Displacement
414cu in
Aspiration
Turbocharged air to air charge cooler
Operational
Operating Weight
49985.5lb
Fuel Capacity
105.7gal
Cooling System Fluid Capacity
6.9gal
Hydraulic System Fluid Capacity
63.5gal
Engine Oil Capacity
6.1gal
Operating Voltage
24V
Swing Drive Fluid Capacity
1.7gal
Alternator Supplied Amperage
80amps
Hydraulic System Relief Valve Pressure
4980psi
Hydraulic Pump Flow Capacity
112.1gal/min
Swing Mechanism
Swing Torque
50662lb ft
Swing Speed
13.3rpm
Buckets
Reference Bucket Capacity
1.2yd3
Minimum Bucket Capacity
0.8yd3
Maximum Bucket Capacity
1.5yd3
