John Deere 2454D Processor Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
35.34ft in
C
Shipping Height Of Unit
13.1ft in
K
Max Reach Along Ground
28.42ft in
M
Max Digging Depth
16.15ft in
Dimensions
E
Ground Clearance
2.33ft in
G
Height To Top Of Cab
13.1ft in
B
Width To Outside Of Tracks
2.3ft in
D
Length Of Track On Ground
35.34ft in
H
Tail Swing Radius
10.67ft in
Removal Counterweight Clearance
4.6ft in
Undercarriage
F
Track Gauge
8.6ft in
N
Shoe Size
27.56in
Number Of Shoes Per Side
45
Ground Pressure
8.37psi
Max Travel Speed
3.42mph
Number Of Carrier Rollers Per Side
2
Drawbar Pull
56075lb
Number Of Track Rollers Per Side
8
Specifications
Engine
Number Of Cylinders
6
Engine Make
John Deere
Engine Model
6068H
Net Power
194.5hp
Aspiration
Turbocharged
Displacement
415cu in
Operational
Operating Weight
73832.9lb
Fuel Capacity
277.4gal
Cooling System Fluid Capacity
7.9gal
Hydraulic System Fluid Capacity
74gal
Operating Voltage
24V
Engine Oil Capacity
6.5gal
Alternator Supplied Amperage
80amps
Hydraulic Pump Flow Capacity
65.5gal/min
Swing Mechanism
Swing Speed
12.6rpm
Swing Torque
56895.6lb ft
