John Deere 25 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
15.39ft in
I
Max Cutting Height
8.67ft in
C
Shipping Height Of Unit
7.81ft in
J
Max Loading Height
9.25ft in
K
Max Reach Along Ground
15.08ft in
L
Max Vertical Wall Digging Depth
4.08ft in
M
Max Digging Depth
9.33ft in
Boom/Stick Option (Hex) 1
Arm Length
Dimensions
B
Width To Outside Of Tracks
4.76ft in
E
Ground Clearance
0.99ft in
G
Height To Top Of Cab
7.83ft in
H
Tail Swing Radius
4.58ft in
Undercarriage
N
Shoe Size
12.6in
F
Track Gauge
3.71ft in
Drawbar Pull
4519lb
Number Of Carrier Rollers Per Side
1
Number Of Track Rollers Per Side
4
Ground Pressure
3.93psi
Max Travel Speed
1.24mph
Specifications
Engine
Number Of Cylinders
3
Engine Make
2348
Engine Model
3TN78-RJB
Gross Power
23hp
Power Measured @
2500rpm
Displacement
75.2cu in
Aspiration
Natural
Operational
Operating Weight
6426lb
Fuel Capacity
12.9gal
Cooling System Fluid Capacity
1.5gal
Hydraulic System Fluid Capacity
22.5gal
Engine Oil Capacity
1.1gal
Hydraulic System Relief Valve Pressure
2133psi
Hydraulic Pump Flow Capacity
25gal/min
Swing Mechanism
Swing Speed
10rpm
Buckets
Reference Bucket Capacity
0.2yd3
