John Deere 27C ZTS Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
13.92ft in
I
Max Cutting Height
13.92ft in
C
Shipping Height Of Unit
8.37ft in
J
Max Loading Height
9.83ft in
K
Max Reach Along Ground
15.42ft in
L
Max Vertical Wall Digging Depth
6.67ft in
M
Max Digging Depth
8.67ft in
Boom/Stick Option (Hex) 1
Arm Length 3ft. 10in. (1170mm )
Dimensions
B
Width To Outside Of Tracks
5.08ft in
D
Length Of Track On Ground
6.33ft in
E
Ground Clearance
1.17ft in
G
Height To Top Of Cab
8.37ft in
H
Tail Swing Radius
2.58ft in
Removal Counterweight Clearance
1.75ft in
Undercarriage
N
Shoe Size
11.82in
Ground Pressure
3.8psi
Max Travel Speed
2.5mph
Specifications
Engine
Engine Make
2353
Engine Model
3LD2
Gross Power
32hp
Power Measured @
2450rpm
Displacement
91.5cu in
Operational
Operating Weight
6482lb
Fuel Capacity
10.5gal
Hydraulic System Fluid Capacity
7.9gal
Operating Voltage
12V
Alternator Supplied Amperage
35amps
Hydraulic Pump Flow Capacity
12.6gal/min
Swing Mechanism
Swing Speed
8.9rpm
Buckets
Reference Bucket Capacity
0.1yd3
Minimum Bucket Capacity
0.1yd3
Maximum Bucket Capacity
0.2yd3
