John Deere 310B Loader Backhoe
Units
Dimensions
Backhoe
K
Reach From Swivel - Std
17.33ft in
L
Dig Depth - Std
14.57ft in
Bucket Dig Force - Std
9600lb
Dimensions
A
Transport Length
23.56ft in
B
Transport Width
6.83ft in
C
Transport Height
11.23ft in
D
Wheelbase
6.83ft in
Rear Tread Range
64.97in
Front Wheel Tread Width
57.88in
Loader
G
Clearance At Max Dump Height
8.76ft in
H
Reach At Max Dump Height
2.43ft in
Bucket Breakout Force
7600lb
Lift Capacity At Full Height
5000lb
Bucket Width
89.38in
Specifications
Engine
Number Of Cylinders
4
Engine Make
John Deere
Gross Power
65hp
Net Power
62hp
Power Measured @
2500rpm
Torque Measured @
1300rpm
Net Max Torque
160lb ft
Displacement
219.7cu in
Bore
4.1in
Stroke
4.4in
Operational
Fuel Capacity
19.5gal
Max Weight
13200lb
Hydraulic System Fluid Capacity
20.5gal
Oil System Fluid Capacity
2.3gal
Cooling System Fluid Capacity
3.1gal
Tire Size Front - 2wd / 4wd
7.50/8.00-16
Rear Tires Size 2wd/4wd
16.9-24
Operating Voltage
12V
Transmission
Transmission Type
Power shuttle
Number Of Forward Gears
8
Number Of Reverse Gears
8
Max Speed - Forward
16.5mph
Max Speed Reverse
18.8mph
Hydraulic
Pump Type
Closed center
Pump Flow Capacity
38gal/min
Relief Valve Pressure
2320psi
