John Deere 3375 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
7.71ft in
E
Ground Clearance
5.52in
C
Height To Top Of Cab
5.75ft in
D
Wheelbase
2.66ft in
F
Length W/O Bucket
5.88ft in
G
Clearance At Max Lift And Dump
6.24ft in
H
Reach At Max Lift And Dump
20.87in
Specifications
Engine
Number Of Cylinders
3
Engine Make
2240
Engine Model
Series 220
Gross Power
19hp
Net Power
17hp
Power Measured @
3400rpm
Displacement
41.8cu in
Operational
Operational Weight
1925lb
Fuel Capacity
6gal
Operating Voltage
12V
Loader
Breakout Force
1400lb
Operating Load Rating
675lb
Tipping Angle
750degrees
Bucket Capacity
0.3yd3
Hydraulic
Pump Type
Open-center
Pump Flow Capacity
8gal/min
Relief Valve Pressure
1600psi
