John Deere 444E Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
9.26ft in
Bucket Capacity - Heaped
1.75yd3
Bucket Capacity - Struck
1.53yd3
Bucket Width
7.94ft in
Breakout Force
18298lb
Dimensions
E
Ground Clearance
1.42ft in
A
Length With Bucket On Ground
20.81ft in
B
Width Over Tires
7.37ft in
C
Height To Top Of Cab
10.41ft in
D
Wheelbase
8.7ft in
F
Hinge Pin - Max Height
11.75ft in
H
Reach At Max Lift And Dump
2.79ft in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2240
Engine Model
4276T
Net Power
95hp
Gross Power
100hp
Power Measured @
2200rpm
Max Torque
284lb ft
Displacement
276cu in
Torque Measured @
1300rpm
Aspiration
Turbocharged
Operational
Operating Weight
18871lb
Fuel Capacity
37gal
Hydraulic System Fluid Capacity
13.3gal
Engine Oil Fluid Capacity
3.5gal
Cooling System Fluid Capacity
9gal
Transmission Fluid Capacity
2gal
Front Axle/Diff Fluid Capacity
4.3gal
Rear Axle/Diff Fluid Capacity
4.3gal
Static Tipping Weight
14487lb
Turning Radius
15ft in
Operating Voltage
12V
Alternator Supplied Amperage
90amps
Rear Axle Oscillation
26degrees
Tire Size
15.5-25
Transmission
Transmission Type
Hydrostatic
Number Of Forward Gears
2
Number Of Reverse Gears
2
Max Speed - Forward
20mph
Max Speed - Reverse
20mph
Hydraulic System
Relief Valve Setting
2987psi
Pump Flow Capacity
38.8gal/min
Raise Time
5.3sec
Dump Time
1sec
Lower Time
3.1sec
Pump Type
Gear
