John Deere 5115M Utility Tractor
Dimensions
Dimensions
Approximate Shipping Weight (Open-Station; Cab)
MFWD: Open: 3975 kg 8765 lb Cab: 4175 kg 9185 lb
Wheelbase - 2wd
92.52in
Wheelbase - Mfwd
92.52in
Specifications
Engine
Number Of Cylinders
4
Family
FJDXL04.5211
Cylinder Liners
Wet sleeved
Rated Power
At 2200 per ISO 97/68/EC: 85 kW 113.9 engine hp
Rated Pto Power
At 2100 per SAE: 74.5 kW 100 PTO hp
Pto Torque Rise
At 1600 rpm: 30 percent
Displacement
274.7cu in
Aspiration
Turbocharged/Air-to-Air Aftercooled
Description
John Deere PowerTech PWL
Capacities
Fuel Tank
Standard: Open: 111.9 L 29.6 U.S. gal. Cab: 139.1 L 36.7 U.S. gal. Optional: Open: 141.2 L 37.3 U.S. gal. Cab: 170.3 L 45.0 U.S. gal.
Def Tank
3.2gal
Transmission
Clutch, Wet/Dry
Wet
Creeper
32F/16R PowrReverser
Reverser
Left hand, mechanical
Transmission Type
Standard: 16F/16R PowrReverser Optional: 12F/4R SyncShuttle Plus 32F/16R PowrReverser Plus
Tires
Wheel Tread Range
MFWD: front: 1299-1997 mm 51.1-78.6 in.
Turning Radius With Brakes
MFWD: 3.85 m 12.6 ft
Front
2WD: 11L-15 8PR F2 Firestone MFWD: 320/85R24 (12.4R24) R1W Radial Firestone
Rear
2WD: 460/85R30 (18.4R30) R1W Firestone MFWD: 460/85R30 (18.4R30) R1W Firestone
Turning Radius Without Brakes
MFWD: 4.0 m 13.1 ft
Hydraulic
Joystick Scv Control
Standard
Pump Rated Output
Standard: 94 L/min 24.7 gpm
Hydraulic Type
Open Center
Available Flow At A Single Rear Scv
70 L/min 18.4 gpm
Rear Hitch
Hitch Draft Control Load Sense Type
Mechanical or electrohydraulic
Hitch Category (Sae Designation)
Category 2; convertible to 1
Remote Control Valves Available
Standard: 2 Optional: 3
Maximum Lift Capacity Behind Lift Points
Standard: 2993 kg 6600 lb
Sensing Type
Lower link
Rear Axle Differential Lock
Electrohydraulic
Rear Power Take -Off (Pto)
Rear Power Take -Off (Pto) Type
Standard: Independent 540/540 Economy Optional: 540/540E/1000
Engine Rpm (At Rated Pto Speeds)
540 at 2100 rpm 540E at 1645 rpm
Pto Actuation
Electrohydraulic
Rear Axle
Final Drive Type
Inboard Planetary
Differential Controls
Electrohydraulic
Axle Type
Flanged
Brakes,Type And Control
Hydraulic wet disc
