John Deere 544EH Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
9.36ft in
Bucket Capacity - Heaped
2.5yd3
Bucket Capacity - Struck
2.12yd3
Bucket Width
8.37ft in
Breakout Force
20558lb
Dimensions
E
Ground Clearance
1.5ft in
A
Length With Bucket On Ground
22.68ft in
B
Width Over Tires
7.94ft in
C
Height To Top Of Cab
10.54ft in
D
Wheelbase
9.52ft in
F
Hinge Pin - Max Height
12.44ft in
H
Reach At Max Lift And Dump
3.04ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6359T
Net Power
125hp
Gross Power
130hp
Power Measured @
2200rpm
Max Torque
372lb ft
Displacement
359cu in
Torque Measured @
1400rpm
Aspiration
Turbocharged
Operational
Operating Weight
23384lb
Fuel Capacity
55gal
Hydraulic System Fluid Capacity
20.1gal
Engine Oil Fluid Capacity
5.1gal
Cooling System Fluid Capacity
6.4gal
Transmission Fluid Capacity
2.6gal
Front Axle/Diff Fluid Capacity
4.3gal
Rear Axle/Diff Fluid Capacity
4.3gal
Static Tipping Weight
17496lb
Turning Radius
16.2ft in
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Rear Axle Oscillation
22degrees
Tire Size
17.5-25
Transmission
Transmission Type
Power Shift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed - Forward
25.4mph
Max Speed - Reverse
17.9mph
Hydraulic System
Relief Valve Setting
2750psi
Pump Flow Capacity
46.3gal/min
Raise Time
5.8sec
Dump Time
1.4sec
Lower Time
3.2sec
Pump Type
Gear
