John Deere 60D Midi Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
18.9ft in
C
Shipping Height Of Unit
8.4ft in
I
Max Cutting Height
19.56ft in
J
Max Loading Height
13.69ft in
M
Max Digging Depth
12.37ft in
Boom/Stick Option (Hex) 1
Boom 9\'9\" (2965mm) / stick 4\' 11\" (1500mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
19ft in
C
Shipping Height Of Unit
8.4ft in
I
Max Cutting Height
20.31ft in
J
Max Loading Height
14.44ft in
M
Max Digging Depth
13.52ft in
Boom/Stick Option (Hex) 2
Boom 9\' 9\" (2965mm) / stick 6\' 1\" (1850mm)
Dimensions
B
Width To Outside Of Tracks
6.58ft in
D
Length Of Track On Ground
6.53ft in
E
Ground Clearance
1.12ft in
G
Height To Top Of Cab
8.4ft in
Removal Counterweight Clearance
2.04ft in
Undercarriage
N
Shoe Size
15.75in
Ground Pressure
4.41psi
Max Travel Speed
2.8mph
Specifications
Engine
Number Of Cylinders
4
Engine Make
2348
Engine Model
4TNV98, Tier IIII certified
Net Power
54hp
Power Measured @
2000rpm
Displacement
194cu in
Operational
Operating Weight
13653.3lb
Fuel Capacity
31.8gal
Operating Voltage
12V
Hydraulic System Fluid Capacity
10.9gal
Engine Oil Capacity
3gal
Alternator Supplied Amperage
50amps
Hydraulic Pump Flow Capacity
38.1gal/min
Swing Mechanism
Swing Speed
9.5rpm
Buckets
Reference Bucket Capacity
0.3yd3
