John Deere 6145M 4WD Tractor
Specifications
Wheelbase
Mfwd Axle Ground Clearance With Standard Mfwd Tyres
20.5in
2wd
108.9in
Mfwd
108.9in
Engine
Engine Manufacturer
John Deere PowerTech™ PSS (B20 Diesel Compatible)
Rated Engine Speed
2100 rpm
Engine Type
Diesel, in-line, 4-cylinder, wet-sleeve cylinder liners with 4 valves-in-head
Rated Power
145hp
Displacement
4 / 4.5 L
Torque Rise
38%
Max Power
153hp
Aspiration
Dual Series Turbocharger w/fi xed geometry fi rst stage-variable geometry second stage - air-to-air aftercooling and cooled exhaust gas recirculation
After Treatment Type
Cooled exhaust gas recirculation (EGR), Diesel Particle Filter (DPF) with Diesel Oxidation Catalyst (DOC) and Selective Catalytic Reduction (SCR) using DEF
Rated Pto Power
114hp
Power Boost (Available In Transport And/Or Mobile Pto Applications)
10 percent
Filter, Engine Air
PowerCore G2 Air Filter with Pre-cleaning
Capacities
Fuel Tank - Diesel
70gal
Def Tank
4gal
Cooling System
7gal
Electrical
Alternator (12-V)
14V, 120 amps (14V, 200 amp Optional)/12V
Power Take-Off(Pto)
Pto Speeds @ Engine Rpm
540 rpm @ 1932 engine rpm
Transmission
Description
e18™ 18-speed PowerShift 40 kph (25 mph); 18F, 6R with Efficiency Manager™
Hydraulic
Maximum Operating Pressure
2900psi
Axles
Flanged Axle, 8 Position Adjustable Steel Wheels
Base
86 X 2550 Mm (3.385 X 100.4 In.) With 2-Position Fixed Cast Wheels
Option
2wd – Tread Range 60.4 To 80.4 In. (1534 To 2042 Mm)
Option
Mfwd - Adjustable Rims
Base
Hydraulic
Selective Control Valves (Rear/Mid)
Pressure Compensated (PC) / Pressure & Flow Compensated (PFC) System with Load Sensing Function (option) up to 3 rear mechanical or 3 with powerbeyond / 3 mid mount mechanical
Main Pump, Axial Piston (Displacement)
35cc
Rated Flow
21.1gal/min
Available Fl Ow At A Single Scv
21.1gal/min
Take Out Oil Capacity Without/With Additional Tank
6.6gal/min
3-Point Hitch
Lift Capacities - Standard
8456lb
Lift Capacities - Optional
9546lb
