John Deere 648G Series II Skidder

Skidder
Skidder
Skidder
Skidder
Skidder
Skidder
Units

Dimensions

Dimensions

A

Overall Length

23.73in

B

Overall Width

10.21ft in

C

Height To Top Of Cab

9.95ft in

E

Ground Clearance

1.69ft in

D

Wheelbase

12.09ft in

F

Max Height Of Boom

10.49ft in

H

Reach Of Grapple At Ground Level

7.36ft in

I

Tong Opening At Tips

9.59ft in

G

Height Of Grapple From Ground

4.52ft in

Max Line Pull - Bare Drum

48767lb

Max Line Speed

146ft/min

Grapple Capacity - Tongs Tip To Tip

10.45ft2

Drum Diameter

8in

Drum Capacity At Cable Width

254ft in

Max Blade Height

51.58in

Cable Width

0.63in


Specifications

Engine

Number Of Cylinders

6

Engine Make

2240

Engine Model

6068T

Gross Power

160hp

Net Power

153hp

Power Measured @

2200rpm

Peak Torque

497lb ft

Torque Measured @

1350rpm

Displacement

414cu in

Aspiration

turbocharged

Operational

Operating Weight

28150lb

Fuel Capacity

60gal

Cooling System Fluid Capacity

7.5gal

Engine Oil Capacity

5gal

Front Diff Fluid Capacity

4.5gal

Rear Diff Fluid Capacity

7.5gal

Transmission Fluid Capacity

7.8gal

Hydraulic System Fluid Capacity

11gal

Operational Voltage

12V

Alternator Supplied Amperage

65amps

Axle Oscillation

30degrees

Steering Angle

90degrees

Tire Size

28L-26

Transmission

Transmission Type

direct-drive power shift

Number Of Forward Gears

8

Number Of Reverse Gears

7

Max Speed - Forward

14.1mph

Max Speed - Reverse

10.7mph

Hydraulic

Pump Type

variable-displacement axial piston

Pump Flow

42gal/min

Relief Valve Pressure

3000psi
