John Deere 650H XLT Crawler Tractor
Units
Dimensions
Dimensions
B
Width Over Tracks
6.59ft in
C
Height To Top Of Cab
9.09ft in
D
Length Of Track On Ground
7.67ft in
E
Ground Clearance
1.2ft in
F
Length W/O Blade
13.96ft in
Undercarriage
H
Standard Shoe Size
18in
Ground Pressure
5.6psi
Track Pitch
6.73in
Ground Contact Area
3312in2
Number Of Track Rollers Per Side
7
Number Of Shoes Per Side
40
Specifications
Engine
Number Of Cylinders
4
Engine Make
2240
Engine Model
4045T
Net Power
90hp
Power Measured @
2200rpm
Max Torque
316lb ft
Displacement
276cu in
Torque Measured @
1200rpm
Aspiration
Altitude-compensating turbocharger
Operational
Operating Weight
18600lb
Fuel Capacity
47gal
Cooling System Fluid Capacity
4.3gal
Engine Oil Capacity
3.7gal
Hydraulic Fluid Capacity
8.5gal
Powertrain Fluid Capacity
11.3gal
Final Drives Fluid Capacity
1.8gal
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Transmission
Transmission Type
Dual-path, electronic-controlled, hydrostatic drive
Max Speed - Forward
5mph
Max Speed - Reverse
5mph
Hydraulic System
Pump Type
Gear
Relief Valve Pressure
3000psi
Pump Flow Capacity
15gal/min
Standard Blade
Width
8.8ft in
Height
36.7in
Capacity
2.6yd3
Blade Angle (Both Directions)
22.2degrees
Cutting Depth
19.7in
