John Deere 710C Loader Backhoe
Units
Dimensions
Backhoe
J
Load Height - Std
13.17ft in
K
Reach From Swivel - Std
22.67ft in
L
Dig Depth - Std
18ft in
M
Reach At Load Height - Std
26.75ft in
Load Height - Ext
15ft in
Bucket Dig Force - Ext
6700lb
Bucket Dig Force - Std
9600lb
Dig Depth - Ext
22.75ft in
Reach At Load Height - Ext
31.17ft in
Load At Max Lift - Ext
3300lb
Load At Max Lift - Std
7300lb
Reach From Swivel - Ext
15ft in
Dimensions
A
Transport Length
26.67ft in
B
Transport Width
8.01ft in
C
Transport Height
13.17ft in
D
Wheelbase
7.88ft in
E
Ground Clearance
1.17ft in
Height To Top Of Suspended Cab
8.83ft in
Loader
G
Clearance At Max Dump Height
9.58ft in
H
Reach At Max Dump Height
2.42ft in
I
Dig Depth
4in
Bucket Breakout Force
13560lb
Bucket Width
96in
Bucket Capacity
1.75yd3
Lift Capacity At Full Height
7100lb
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6059T
Gross Power
120hp
Net Power
115hp
Power Measured @
2200rpm
Net Torque Rise
25%
Net Max Torque
343lb ft
Displacement
359cu in
Operational
Fuel Capacity
37gal
Max Weight
22500lb
Hydraulic System Fluid Capacity
40gal
Oil System Fluid Capacity
5.1gal
Cooling System Fluid Capacity
6.9gal
Transmission Fluid Capacity
6gal
Rear Axle Fluid Capacity
4.5gal
Turning Radius
14.4ft in
Tire Size Front - 2wd / 4wd
14.5/75-16.1,10PR F3
Rear Tires Size 2wd/4wd
21L-24,16PR R4/20.5-25,12PR R4
Operating Voltage
12V
Alternator Supplied Amperage
78amps
Transmission
Transmission Type
Powershift with modulated full power shifting between forward and reverse
Number Of Forward Gears
4
Number Of Reverse Gears
2
Max Speed - Forward
21mph
Max Speed Reverse
6.6mph
Hydraulic
Pump Type
Radial pistons
Pump Flow Capacity
53gal/min
Relief Valve Pressure
2550psi
