John Deere 75G Midi Excavator
Units
Dimensions
Dimensions
E
Ground Clearance
1.19ft in
H
Tail Swing Radius
4.24ft in
F
Track Gauge
6.14ft in
Digging Reach - Mono Boom
22.71ft in
Dozer Blade Height
18.9in
Dozer Blade Width
91.34in
Dump Height - Mono Boom
18.08ft in
Ground Level Reach - Mono Boom
22.18ft in
Overall Width
7.62ft in
Standard Dipper
6.96ft in
Track Length On Ground
7.52ft in
Transport Height - Maximum
8.83ft in
Transport Length Mono Boom
20.9ft in
Undercarriage Overall Length
9.59ft in
Dig Depth - 2.44m 8 Ft Flat Bottom
14.18ft in
Width Over Standard Tracks
7.62ft in
Dig Depth - Mono Boom
15.13ft in
Dig Height - Mono Boom
24.97ft in
Specifications
Driveline
Displacement
201.4cu in
Engine Manufacturer
Yanmar
Emission Rating
Tier 4
Rated Speed
2000rpm
Engine Output - Net
56.9hp
Track Shoe Width
17.8in
Number Of Cylinders
4
Number Of Carrier Rollers - Each Side
1
Number Of Track Rollers - Each Side
5
Capacities
Fuel Tank - Diesel
35.7gal
Hydraulic Tank
14.8gal
System Voltage
24V
Number Of Batteries
2
Performance
Tractive Force
14657.6lb
Slew Speed
10.5rpm
Ground Bearing Pressure
5.6psi
Slew Torque
12.3lb ft
Breakout - Bucket
10476.1lb
Bucket Pressure
260
Dipper Tearout
6901.7lb
Gradeability
70%
Main Pumps - Maximum Flow
38.1gal/min
Travel Speed - High
3.2mph
Weights
Operating Weight
17952.3lb
