John Deere 76F Open Station MFWD Tractor
Units
Dimensions
Dimensions
D
Wheelbase
6.09ft in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2393
Gross Power
76hp
Pto Power
66hp
Power Measured @
2600rpm
Max Torque
192lb ft
Torque Measured @
1400rpm
Displacement
164.8cu in
Aspiration
turbocharged
Operational
Fuel Capacity
13.3gal
3 Point Hitch Lift Capacity @ 24 Inches
5070.7lb
Turning Radius
10.9ft in
Tire Size Front - 2wd / 4wd
240/70x16
Rear Tires Size 2wd/4wd
380/70x24
Transmission
Transmission Type
8+8/16+8 Sync Reverser
Hydraulic System
Relief Valve Setting
2828psi
Pump Flow Capacity
9.3gal/min
Number Of Remote Control Valves
1
