John Deere 950C LT Crawler Tractor
Units
Dimensions
Dimensions
B
Width Over Tracks
9.76ft in
C
Height To Top Of Cab
10.85ft in
D
Length Of Track On Ground
10.75ft in
E
Ground Clearance
1.59ft in
F
Length W/O Blade
14.11ft in
Undercarriage
G
Track Gauge
6.5ft in
Ground Pressure
10.1psi
Track Pitch
8.5in
Ground Contact Area
5160in2
Number Of Track Rollers Per Side
8
Number Of Shoes Per Side
43
Specifications
Engine
Number Of Cylinders
6
Engine Make
2245
Engine Model
D 926 TI
Net Power
230hp
Power Measured @
1800rpm
Max Torque
797lb ft
Displacement
610cu in
Torque Measured @
1300rpm
Aspiration
Intercooled and turbocharged
Operational
Operating Weight
52300lb
Fuel Capacity
119gal
Cooling System Fluid Capacity
17.6gal
Engine Oil Capacity
6.7gal
Hydraulic Fluid Capacity
47gal
Powertrain Fluid Capacity
47gal
Final Drives Fluid Capacity
3.8gal
Operating Voltage
24V
Alternator Supplied Amperage
55amps
Transmission
Transmission Type
Dual-path, electronic-controlled, closed-loop hydrostatic drive
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
6.8mph
Max Speed - Reverse
6.8mph
Hydraulic System
Pump Type
Variable-displacement piston pump with load-sensing proportional pump flow
Relief Valve Pressure
2320psi
Pump Flow Capacity
77gal/min
Standard Blade
Width
13.1ft in
Height
57in
Capacity
9.5yd3
Blade Angle (Both Directions)
25degrees
Cutting Depth
21in
