John Deere JD570 Motor Grader
Units
Dimensions
Dimensions
A
Overall Length
24.33ft in
B
Width Over Tires
7.83ft in
D
Wheelbase
17.33ft in
G
Tandem Axle Wheelbase
4.75ft in
F
Front Ground Clearance
1.96ft in
H
Blade Base
7.67ft in
Height To Top Of Isomount Cab
10.5ft in
Specifications
Engine
Engine Make
2240
Power Measured @
2300rpm
Torque Measured @
1300rpm
Max Power
83hp
Net Power Gears 7-8
83hp
Net Torque Gears 7-8
212lb ft
Displacement
303.6cu in
Aspiration
Natural
Operational
Std Operation Weight - Front Axle
5500lb
Hydraulic System Fluid Capacity
21gal
Std Operation Weight - Rear Axle
12600lb
Std Operation Weight - Total
20278lb
Max Operation Weight - Front Axle
5800lb
Max Operation Weight - Rear Axle
13600lb
Max Operation Weight - Total
18100lb
Oil System Fluid Capacity
2.5gal
Fuel Capacity
50gal
Cooling System Fluid Capacity
5.5gal
Circle Gearbox Fluid Capacity
1.5gal
Tandem Case Fluid Capacity (Each)
5gal
Tire Size
13.00-24
Operating Voltage
12V
Steering
Articulation Angle
22degrees
Turning Radius
18ft in
Transmission
Transmission Type
Power shift
Number Of Gears - Forward
8
Number Of Gears - Reverse
4
Max Speed - Forward
21.4mph
Max Speed - Reverse
6.8mph
Front Axle
Wheel Lean
20degrees
Oscillation - Total
30degrees
Ground Clearance
2ft in
Moldboard
Moldboard Width
12ft in
Moldboard Height
24in
Moldboard Thickness
0.7in
Side Shift Left
26.8in
Side Shift Right
31.3in
Hydraulic System
Pump Type
Piston Pump
Pump Flow
26.9gal/min
Relief Valve Pressure
2000psi
Circle
Diameter
54in
Rotation
360degrees
Max Lift Above Ground
12.3in
