Kawasaki 65TMV Integrated Tool Carrier
Units
Dimensions
Dimensions
A
Length W/ Bucket On Ground
23.66ft in
B
Width Over Tires
7.9ft in
C
Height To Top Of Cab
10.73ft in
D
Wheelbase
9.52ft in
E
Ground Clearance
1.46ft in
F
Hinge Pin Max Height
13.06ft in
G
Dump Clearance At Max Lift
9.68ft in
K
Max Lift Height
12.59ft in
I
Fork Tine Length
4ft in
L
Hook Height At Max Lift - Standard
19.08ft in
M
Hook Height At Max Lift - Extended
23.46ft in
N
Hook Reach At Max Lift - Standard
9.42ft in
O
Hook Reach At Max Lift - Extended
13.83ft in
P
Hook Max Reach - Standard
7.49ft in
Q
Hook Max Reach - Extended
13.67ft in
R
Height At Hook Max Reach
6.81ft in
Length With Out Forks On Ground
25.1ft in
Reach At Max Height And Dump
3.6ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
6BTAA5.9
Net Power
134hp
Power Measured @
2200rpm
Max Torque
401lb ft
Torque Measured @
1500rpm
Displacement
359cu in
Aspiration
turbocharged 7 intercooler
Operational
Operating Weight
26411.4lb
Fuel Capacity
58.7gal
Cooling System Fluid Capacity
11.4gal
Engine Oil Capacity
4.3gal
Transmission Fluid Capacity
8gal
Front Diff Fluid Capacity
6.7gal
Rear Diff Fluid Capacity
6.7gal
Hydraulic System Fluid Capacity
26.5gal
Turning Radius
18.7ft in
Operating Voltage
24V
Alternator Supplied Amperage
50amps
Rear Axle Oscillation
12degrees
Static Tipping Load - Bucket
18166.1lb
Static Tipping Load - Forks
13602.6lb
Static Tipping Load - Material Handler
8862.6lb
Tire Size
20.5x25-12PR (L-2)
Transmission
Transmission Type
full power shift
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed Forward
24.7mph
Max Speed Reverse
24.7mph
Hydraulic System
Pump Type
gear type
Relief Valve Setting
3000psi
Pump Flow Capacity
27.7gal/min
Raise Time
5.8sec
Dump Time
2.2sec
Lower Time
2.9sec
Bucket
Breakout Force
24100lb
Bucket Capacity - Heaped
2.8yd3
Bucket Capacity - Struck
2.3yd3
