Kobelco 35SR ACERA Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
15.46ft in
I
Max Cutting Height
16.34ft in
C
Shipping Height Of Unit
8.57ft in
J
Max Loading Height
11.75ft in
K
Max Reach Along Ground
16.77ft in
L
Max Vertical Wall Digging Depth
7.85ft in
M
Max Digging Depth
10.11ft in
Boom/Stick Option (Hex) 1
Boom 8\'2\" (2500mm) / Stick 4\'4\" (1320mm)
Boom/Stick Option (Hex) 2
I
Max Cutting Height
16.93ft in
A
Shipping Length Of Unit
16.08ft in
J
Max Loading Height
12.34ft in
C
Shipping Height Of Unit
8.57ft in
K
Max Reach Along Ground
17.62ft in
L
Max Vertical Wall Digging Depth
8.7ft in
M
Max Digging Depth
11ft in
Boom/Stick Option (Hex) 2
Boom 8\'2\" (2500mm) / Stick 5\'3\" (1590mm)
Dimensions
B
Width To Outside Of Tracks
5.58ft in
D
Length Of Track On Ground
5.58ft in
E
Ground Clearance
1.09ft in
G
Height To Top Of Cab
8.57ft in
H
Tail Swing Radius
2.79ft in
Removal Counterweight Clearance
1.88ft in
Undercarriage
N
Shoe Size
11.82in
F
Track Gauge
4.6ft in
Max Travel Speed
2.8mph
Ground Pressure
4.64psi
Specifications
Engine
Number Of Cylinders
3
Engine Make
2348
Engine Model
3TNV88-BPYB
Net Power
28.4hp
Power Measured @
2400rpm
Displacement
100cu in
Max Torque
72.2lb ft
Torque Measured @
1440rpm
Operational
Operating Weight
7958.7lb
Fuel Capacity
10.1gal
Cooling System Fluid Capacity
1.3gal
Hydraulic System Fluid Capacity
12.7gal
Engine Oil Capacity
1.8gal
Operational Voltage
12V
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
3336psi
Hydraulic Pump Flow Capacity
20.3gal/min
Swing Mechanism
Swing Speed
8.9rpm
Buckets
Reference Bucket Capacity
0.2yd3
Minimum Bucket Capacity
0.1yd3
Maximum Bucket Capacity
0.3yd3
