Kobelco ED160-3 BLADE RUNNER Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
M
Max Digging Depth
0.02ft in
Boom/Stick Option (Hex) 1
Arm 7\' 10\" {2.38m}
Horizontal Digging Stroke - Ground Level
0.02ft in
Max Digging Height
0.04ft in
Max Digging Reach
0.03ft in
Max Digging Reach On Ground
0.03ft in
Max Dumping Clearance
0.03ft in
Min Dumping Clearance
0.01ft in
Boom/Stick Option (Hex) 2
L
Max Vertical Wall Digging Depth
0.02ft in
M
Max Digging Depth
0.02ft in
Max Digging Reach On Ground
0.03ft in
Min Dumping Clearance
7.81ft in
Max Digging Reach
0.03ft in
Max Dumping Clearance
0.03ft in
Boom/Stick Option (Hex) 2
Arm 9\' 4\" {2.84m}
Minimum Swing Radius
0.1in
Dimensions
G
Height To Top Of Cab
9.95ft in
H
Tail Swing Radius
4.89ft in
F
Track Gauge
6.53ft in
Shoe Width
1.97ft in
Gradeability
35%
Overall Length
11.82ft in
Overall Width
101.97in
Overall Width Of Superstructure
8.17ft in
Undercarriage
N
Shoe Size
23.63in
Ground Pressure
6.09psi
Drawbar Pull
44062.55lb
Specifications
Engine
Number Of Cylinders
4
Engine Model
D04EG-TAA
Net Power
92.8hp
Power Measured @
2000rpm
Max Torque
265lb ft
Displacement
203.4cu in
Operational
Operating Weight
35053.5lb
Fuel Capacity
52.9gal
Cooling System Fluid Capacity
3.7gal
Hydraulic System Fluid Capacity
33.5gal
Engine Oil Capacity
4.9gal
Swing Drive Fluid Capacity
0.5gal
Hydraulic Pump Flow Capacity
22.6gal/min
Swing Mechanism
Swing Speed
11rpm
Swing Torque
29.5lb ft
Buckets
Bucket Digging Force - Sae
19715.8lb
Arm Crowding Force -Sae
14005.6lb
Arm Crowding Force - Iso
14477.7lb
Blade
Blade Lift Height
32.1in
Hydraulic System
Max. Discharge Flow
34.4gal/min
Blade
Width
10.7ft in
