Komatsu D45S Crawler Loader
Units
Dimensions
Dimensions
A
Length With Bucket On Ground
16.11ft in
B
Width To Outside Of Tracks
6.39ft in
G
Clearance At Full Height And Dump
8.54ft in
H
Reach At Dump Height
3.38ft in
Undercarriage
I
Track Gauge
60.63in
D
Length Of Track On Ground
6.76ft in
Number Of Track Rollers Per Side
5
Track Shoe Width
15.75in
Ground Pressure
9.39psi
Specifications
Engine
Engine Make
2238
Engine Model
S4D105
Net Power
90hp
Displacement
264cu in
Operational
Operating Weight
24118.6lb
Fuel Capacity
55.5gal
Cooling System Fluid Capacity
11.4gal
Static Tipping Load
15700lb
Breakout Force - Std Bucket
13230lb
Bucket Capacity - Heaped
1.6yd3
Max Speed
5.1mph
