Komatsu PC750LC-7 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
45.58ft in
C
Shipping Height Of Unit
15.91ft in
I
Max Cutting Height
39.23ft in
J
Max Loading Height
270.13ft in
K
Max Reach Along Ground
43.97ft in
L
Max Vertical Wall Digging Depth
17.16ft in
M
Max Digging Depth
27.71ft in
Boom/Stick Option (Hex) 1
boom 8040mm w/ arm 3600mm
Dimensions
E
Ground Clearance
2.76ft in
G
Height To Top Of Cab
11.31ft in
B
Width To Outside Of Tracks
13.82ft in
D
Length Of Track On Ground
16.47ft in
H
Tail Swing Radius
14.11ft in
Removal Counterweight Clearance
5.12ft in
Undercarriage
F
Track Gauge
11.48ft in
N
Shoe Size
27.96in
Drawbar Pull
125660lb
Number Of Carrier Rollers Per Side
3
Max Travel Speed
2.61mph
Number Of Shoes Per Side
47
Number Of Track Rollers Per Side
8
Ground Pressure
12.42psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2238
Engine Model
SAA6D140E-3
Net Power
454hp
Power Measured @
1800rpm
Aspiration
Turbocharged with aftercooler
Displacement
930.1cu in
Operational
Operating Weight
177791.8lb
Fuel Capacity
232.5gal
Cooling System Fluid Capacity
22.5gal
Hydraulic System Fluid Capacity
116.3gal
Engine Oil Capacity
14.6gal
Swing Drive Fluid Capacity
5.3gal
Hydraulic System Relief Valve Pressure
4980psi
Hydraulic Pump Flow Capacity
261.1gal/min
Swing Mechanism
Swing Speed
6.8rpm
Buckets
Reference Bucket Capacity
5.3yd3
