Komatsu PC750SE-6 Shovel
Units
Dimensions
Backhoe Boom / Stick 1
A
Overall Length
42.22ft in
M
Max Dig Depth
23.02ft in
C
Height To Top Of Boom
15.44ft in
L
Max Vertical Wall Dig Depth
16.18ft in
Q
Max Cutting Height
37.77ft in
R
Max Dump Height
24.82ft in
Backhoe Boom / Stick
Boom 7100mm / Stick 2920mm
Arm Crowd Force
74516lb ft
Max Reach On Ground
38.93ft in
Backhoe Boom / Stick 2
I
Max Cutting Height
39.22ft in
J
Max Dump Height
27ft in
A
Overall Length
45.34ft in
L
Max Vertical Wall Dig Depth
19.24ft in
C
Height To Top Of Boom
15.7ft in
T
Max Dig Depth
27.7ft in
Max Reach On Ground
43.96ft in
Backhoe Boom / Stick
Boom 8200mm / Stick 3600mm
Arm Crowd Force
64154lb ft
Dimensions
B
Width Over Tracks
14.14ft in
D
Length Of Track On Ground
14.76ft in
G
Height To Top Of Cab
13.51ft in
E
Ground Clearance
2.76in
Length Of Tracks
19.06ft in
Upper Structure Ground Clearance
5.11ft in
Loading Shovel
S
Max Dig Reach
32.68ft in
R
Max Dump Height
25.04ft in
Q
Max Cutting Height
34.78ft in
T
Max Dig Depth
11.23ft in
P
Height To Top Of Boom - Shovel
16.65ft in
U
Overall Length - Shovel
32.03ft in
Loading Shovel
3.8 m (cube) bottom dump bucket
Arm Crowd Force
99208lb ft
Undercarriage
H
Tail Swing Radius
14.1ft in
F
Track Gauge
9.12ft in
Backhoe Ground Pressure - Shoe 1
18psi
Backhoe Shoe Width 3
31.89in
Backhoe Shoe Width 2
27.96in
Backhoe Shoe Width 1
24.02in
Backhoe Operating Weight - Shoe 3
171177.94lb
Max Travel Speed
2.61mph
Backhoe Operating Weight - Shoe 2
169634.7lb
Backhoe Operating Weight - Shoe 1
168091.47lb
Number Of Lower Rollers
8
Number Of Track Shoes Per Side
3
Number Of Upper Rollers
47
Backhoe Ground Pressure - Shoe 3
13.8psi
Backhoe Ground Pressure - Shoe 2
15.6psi
Specifications
Engine
Engine Make
2238
Engine Model
SAA6D140E-2
Net Power
444hp
Aspiration
Turbocharged
Displacement
930.1cu in
Operational
Fuel Capacity
232.5gal
Cooling System Fluid Capacity
22.5gal
Engine Oil Capacity
10.1gal
Hydraulic System Fluid Capacity
116.3gal
Swing Speed
5.7rpm
