Komatsu WA200-7 Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
9.73ft in
Bucket Width
8.35ft in
Breakout Force
24250.14lb
Dimensions
E
Ground Clearance
1.63ft in
A
Length With Bucket On Ground
23.27ft in
B
Width Over Tires
8.11ft in
D
Wheelbase
9.32ft in
F
Hinge Pin - Max Height
12.75ft in
H
Reach At Max Lift And Dump
3.12ft in
Specifications
Engine
Emissions Certification
IIIB/EPA Tier 4 interim
Number Of Cylinders
4
Engine Make
Komatsu
Engine Model
SAA4D107E-2
Net Power
126hp
Gross Power
128hp
Power Measured @
2000rpm
Displacement
272.2cu in
Aspiration
Turbocharged
Bore
4.3in
Stroke
4.9in
Operational
Operating Weight
25342.2lb
Fuel Capacity
46.8gal
Hydraulic System Fluid Capacity
15.4gal
Engine Oil Fluid Capacity
4.1gal
Cooling System Fluid Capacity
6.5gal
Transmission Fluid Capacity
1.4gal
Front Axle/Diff Fluid Capacity
4.9gal
Rear Axle/Diff Fluid Capacity
4.8gal
Turning Radius
16.1ft in
Operating Voltage
24V
Alternator Supplied Amperage
60amps
Tire Size
20.5 R25
Transmission
Transmission Type
Electronically controlled hydrostatic transmission
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed - Forward
23.7mph
Max Speed - Reverse
23.7mph
Hydraulic System
Relief Valve Setting
20.6 Mpa
Pump Flow Capacity
22.5gal/min
Raise Time
5.7sec
Dump Time
1.9sec
Lower Time
3.2sec
Pump Type
Gear type pump
System Pressure
3000psi
