Komatsu WA500-3L Wheel Loader
Units
Dimensions
Dimensions
E
Ground Clearance
1.5ft in
A
Length With Bucket On Ground
30.2ft in
B
Width Over Tires
10.5ft in
C
Height To Top Of Cab
12.7ft in
D
Wheelbase
11.8ft in
F
Hinge Pin - Max Height
14.8ft in
H
Reach At Max Lift And Dump
4.3ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2238
Engine Model
SAD140E
Gross Power
315hp
Power Measured @
2100rpm
Displacement
927.6cu in
Aspiration
TURBOCHARGED
Operational
Operating Weight
64970.2lb
Fuel Capacity
121.5gal
Hydraulic System Fluid Capacity
46.2gal
Engine Oil Fluid Capacity
9.8gal
Cooling System Fluid Capacity
26.2gal
Transmission Fluid Capacity
16.4gal
Front Axle/Diff Fluid Capacity
20.6gal
Rear Axle/Diff Fluid Capacity
20.6gal
Static Tipping Weight
51588.2lb
Turning Radius
21.4ft in
Operating Voltage
24V
Alternator Supplied Amperage
50amps
Rear Axle Oscillation
30degrees
Tire Size
25-26.5
Transmission
Transmission Type
POWERSHIFT
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed - Forward
20.5mph
Max Speed - Reverse
22.4mph
Hydraulic System
Relief Valve Setting
3045.8psi
Pump Flow Capacity
91.9gal/min
Raise Time
6.4sec
Dump Time
1.7sec
Lower Time
3.5sec
Pump Type
GEAR PUMP
