Komatsu WA70-6 Wheel Loader
Units
Dimensions
Bucket
Bucket Capacity - Heaped
1.12yd3
Dimensions
E
Ground Clearance
1.01ft in
A
Length With Bucket On Ground
17.87ft in
B
Width Over Tires
5.34ft in
C
Height To Top Of Cab
8.09ft in
D
Wheelbase
6.73ft in
F
Hinge Pin - Max Height
10.34ft in
H
Reach At Max Lift And Dump
3.07ft in
Specifications
Engine
Number Of Cylinders
4
Engine Make
Komatsu
Engine Model
4D95LWE-5
Gross Power
60.3hp
Torque
154.9lb ft
Power Measured @
2.4rpm
Torque Measured @
1.6rpm
Bore
3.8in
Stroke
4.6in
Operational
Operating Weight
11155.4lb
Fuel Capacity
34.9gal
Hydraulic System Fluid Capacity
13.3gal
Engine Oil Fluid Capacity
2gal
Cooling System Fluid Capacity
2.5gal
Front Axle/Diff Fluid Capacity
2.3gal
Rear Axle/Diff Fluid Capacity
2.3gal
Alternator Supplied Amperage
90amps
Transmission
Number Of Forward Gears
2
Number Of Reverse Gears
2
Max Speed - Forward
3.2mph
Max Speed - Reverse
12.5mph
Hydraulic System
Pump Flow Capacity
14.1gal/min
Raise Time
5.3sec
Dump Time
1.1sec
Lower Time
3sec
