Kubota KX033-4HGAX Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
L
Max Vertical Wall Digging Depth
7.34ft in
M
Max Digging Depth
10.54ft in
Boom Offset-Left
1.48ft in
Boom Offset-Right
1.35ft in
Max Digging Height
16.34ft in
Max.Dumping Height
11.59ft in
Mximum Dig Radius
205.91in
Dimensions
D
Length Of Track On Ground
15.52ft in
E
Ground Clearance
0.96ft in
Height
97.64in
Shoe Width
0.99ft in
Width
5.09ft in
Undercarriage
Max Travel Speed
2.9mph
Ground Pressure
4.37psi
Specifications
Engine
Engine Make
Kubota
Engine Model
D1703M-DI-E4
Engine Type
Water cooled
Gross Power
24.8hp
Net Power
23.2hp
Power Measured @
2200rpm
Displacement
100.5cu in
Fuel Type
Diesel
Model Name
KX033-4HGAX
Operational
Operating Weight
7616lb
Fuel Capacity
12.4gal
Hydraulic System Fluid Capacity
11.8gal
Hydraulic Pump Flow Capacity
16.2gal/min
Swing Mechanism
Swing Speed
8.9rpm
Blade
Maximum Drop Below Ground
1.3ft in
Maximum Lift Above Ground
1.2ft in
Height
13.6in
Width
5.1ft in
Blade Lift-Upper
1.2ft in
Blade Lift-Left
1.3ft in
Drive System
Max. Traction Force-Low Speed
6091lb
Tumbler Distance
5.5ft in
Crawler Length
6.9ft in
