Kubota L4330GST 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
10.11in
B
Width Outside Frame
5.55ft in
C
Height To Top Of Cab
7.6ft in
D
Wheelbase
6.22in
E
Ground Clearance
14.77in
Tire Size
front 8.3-16 rear 14.9-24
Specifications
Engine
Number Of Cylinders
4
Engine Make
2334
Engine Model
L4330 GST
Net Power
41hp
Gross Power
43.2hp
Pto Power
36hp
Power Measured @
2600rpm
Displacement
134.1cu in
Aspiration
E-TVCS indirect injection
Operational
Fuel Capacity
10.6gal
Operating Weight
3472.3lb
3 Point Hitch Type
Cat. I
3 Point Hitch Lift Capacity @ 24 Inches
2755.8lb
Turning Radius
9.6ft in
Operating Voltage
12V
Alternator Supplied Amperage
40amps
Transmission
Transmission Type
GST
Number Of Forward Gears
12
Number Of Reverse Gears
8
Max Speed
16.3mph
Hydraulic System
Pump Flow Capacity
14.2gal/min
