Kubota M5-091HDRC 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
155.91in
B
Width Outside Frame
6.53ft in
C
Height To Top Of Cab
8.24ft in
D
Wheelbase
88.59in
E
Ground Clearance
18.71in
Front Tread Range
62.21in
Rear Tread Range
59.8-75.6 in, 1520-1920 mm
Specifications
Engine
Number Of Cylinders
4
Engine Make
KUBOTA
Engine Type
4 cylinders in-line, Common Rail System, direct injection
Gross Power
92.5hp
Net Power
85.5hp
Pto Power
76hp
Power Measured @
2400rpm
Displacement
230cu in
Aspiration
Turbocharged
Model Name
M5-091HDRC
Operational
Operating Weight
6150.9lb
Fuel Capacity
27.8gal
3 Point Hitch Type
Category 2
3 Point Hitch Lift Capacity @ 24 Inches
4629.8lb
Turning Radius
13.8ft in
Tire Size Front - 2wd / 4wd
11.2-24 R1
Rear Tires Size 2wd/4wd
16.9-30 R1
Alternator Supplied Amperage
80amps
Power Take-Off(Pto)
Pto Speed
540rpm
Power Take-Off(Pto) Type
Live-independent PTO, electro-hydraulic clutch with brake
Transmission
Gear Type
Fully synchronized
Shuttle Type
Electro-hydraulic shuttle
Brakes
Hydraulic wet disc
Steering
Hydrostatic power steering
Clutch, Wet/Dry
Multiple wet disc
Differential Lock
Limited Slip Differential / mechanical
Number Of Forward Gears
8
Number Of Reverse Gears
8
Hydraulic System
Pump Flow Capacity
15.7gal/min
Number Of Remote Control Valves
1
