Kubota M6800 4WD Tractor

4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
Units

Dimensions

Dimensions

A

Overall Length

11.82in

B

Width Outside Frame

6.11ft in

C

Height To Top Of Cab

8.27ft in

D

Wheelbase

6.98in

E

Ground Clearance

18.12in

Tire Size

front 9.5-24R1 rear 16.9-30R1


Specifications

Engine

Number Of Cylinders

4

Engine Make

2334

Engine Model

V3300-E

Gross Power

70.9hp

Pto Power

62hp

Power Measured @

2600rpm

Displacement

202cu in

Aspiration

E-TVCS liquid cooled

Operational

Operating Weight

6173lb

Fuel Capacity

25.1gal

Cooling System Fluid Capacity

2.3gal

Engine Oil Capacity

2.9gal

3 Point Hitch Type

Cat I & II

3 Point Hitch Lift Capacity @ 24 Inches

3307lb

Turning Radius

10.2ft in

Operating Voltage

12V

Transmission

Transmission Type

fully synchronized

Number Of Forward Gears

8

Number Of Reverse Gears

8

Hydraulic System

Pump Flow Capacity

17.1gal/min

Axles

Final Drive

inboard planetary

Hydraulic System

Number Of Remote Control Valves

1


Compare similar models

Manufacturer/Model

3 Point Hitch Lift Capacity @ 24 Inches

Gross Power

Operating Weight

3 Point Hitch Lift Capacity @ 24 Inches

3520 lb

Gross Power

71 hp

Operating Weight

6349.4 lb

3 Point Hitch Lift Capacity @ 24 Inches

3520 lb

Gross Power

66 hp

Operating Weight

5996.6 lb

3 Point Hitch Lift Capacity @ 24 Inches

3947 lb

Gross Power

72 hp

Operating Weight

6305 lb
