Liebherr R974C Shovel
Units
Dimensions
Backhoe Boom / Stick 1
M
Max Dig Depth
24.45ft in
Q
Max Cutting Height
40.69ft in
R
Max Dump Height
27.07ft in
Max Reach On Ground
40.03ft in
Backhoe Boom / Stick
7.2 boom / 2.9m stick
Backhoe Boom / Stick 2
I
Max Cutting Height
42.33ft in
J
Max Dump Height
28.55ft in
T
Max Dig Depth
27.4ft in
Max Reach On Ground
42.82ft in
Backhoe Boom / Stick
7.2 boom / 3.8 stick
Backhoe Boom / Stick 3
I
Max Cutting Height
43.97ft in
J
Max Dump Height
30.19ft in
M
Max Dig Depth
30.35ft in
Backhoe Boom / Stick
7.2m boom / 4.7m stick
Max Reach On Ground
45.77ft in
Backhoe Boom / Stick 4
I
Max Cutting Height
44.13ft in
J
Max Dump Height
30.52ft in
M
Max Dig Depth
29.7ft in
Backhoe Boom / Stick
8.6m boom / 2.9m stick
Max Reach On Ground
44.95ft in
Dimensions
B
Width Over Tracks
14.22ft in
D
Length Of Track On Ground
15.23ft in
G
Height To Top Of Cab
12.57ft in
E
Ground Clearance
2.09in
Height Of Tracks
4.98ft in
Upper Structure Ground Clearance
5.35ft in
Length Of Tracks
19.15ft in
Loading Shovel
S
Max Dig Reach
30.68ft in
R
Max Dump Height
26.09ft in
Q
Max Cutting Height
32.81ft in
T
Max Dig Depth
9.85ft in
Arm Crowd Force
_-
Loading Shovel
Shovel Attachment
Undercarriage
N
Loading Shovel Shoe Width
19.69in
F
Track Gauge
11.82ft in
Backhoe Shoe Width 1
19.69in
Backhoe Operating Weight - Shoe 3
190038.49lb
Backhoe Operating Weight - Shoe 2
187613.4lb
Backhoe Operating Weight - Shoe 1
186070.16lb
Backhoe Shoe Width 3
29.53in
Number Of Lower Rollers
8
Number Of Upper Rollers
2
Loading Shovel Operating Weight
197093.28lb
Max Travel Speed
2.74mph
Backhoe Shoe Width 2
23.63in
Specifications
Engine
Number Of Cylinders
8
Engine Make
2245
Engine Model
D 9508
Gross Power
543hp
Power Measured @
1800rpm
Displacement
986.2cu in
Aspiration
Common-rail-injection turbo-charged after-cooled reduced emissions
Operational
Fuel Capacity
385.7gal
Hydraulic System Fluid Capacity
356.7gal
Swing Speed
5.9rpm
Operating Voltage
24V
Alternator Supplied Amperage
80amps
