Link-Belt 130X2LC Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
25ft in
C
Shipping Height Of Unit
9.45ft in
I
Max Cutting Height
28.78ft in
J
Max Loading Height
20.97ft in
K
Max Reach Along Ground
26.81ft in
L
Max Vertical Wall Digging Depth
16.25ft in
M
Max Digging Depth
18.18ft in
Boom/Stick Option (Hex) 1
Boom 15\'2\" (4630mm) / Stick 8\'2\" (2500mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
25.07ft in
I
Max Cutting Height
29.7ft in
C
Shipping Height Of Unit
9.45ft in
J
Max Loading Height
21.92ft in
K
Max Reach Along Ground
28.35ft in
L
Max Vertical Wall Digging Depth
17.56ft in
M
Max Digging Depth
19.85ft in
Boom/Stick Option (Hex) 2
Boom 15\'2\" (4630mm) / Stick 9\'10\" (3010mm)
Dimensions
E
Ground Clearance
1.45ft in
G
Height To Top Of Cab
9.45ft in
B
Width To Outside Of Tracks
8.5ft in
D
Length Of Track On Ground
9.98ft in
H
Tail Swing Radius
6.99ft in
Removal Counterweight Clearance
2.94ft in
Undercarriage
F
Track Gauge
6.53ft in
N
Shoe Size
23.63in
Ground Pressure
4.64psi
Number Of Shoes Per Side
46
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.5mph
Number Of Track Rollers Per Side
7
Specifications
Engine
Number Of Cylinders
4
Engine Make
2353
Engine Model
AJ-4JJ1X
Net Power
95hp
Power Measured @
2000rpm
Max Torque
265lb ft
Displacement
183.1cu in
Aspiration
Turbocharged
Torque Measured @
1600rpm
Operational
Operating Weight
28440lb
Fuel Capacity
68.7gal
Cooling System Fluid Capacity
3.9gal
Hydraulic System Fluid Capacity
41.5gal
Operating Voltage
24V
Engine Oil Capacity
4.5gal
Swing Drive Fluid Capacity
0.6gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4970psi
Hydraulic Pump Flow Capacity
68.2gal/min
Swing Mechanism
Swing Speed
14rpm
Swing Torque
24340lb ft
Buckets
Reference Bucket Capacity
0.7yd3
Minimum Bucket Capacity
0.5yd3
Maximum Bucket Capacity
1yd3
