Link-Belt 240X2 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
32.58ft in
C
Shipping Height Of Unit
10.34ft in
I
Max Cutting Height
32.03ft in
J
Max Loading Height
22.18ft in
K
Max Reach Along Ground
33.14ft in
L
Max Vertical Wall Digging Depth
20.15ft in
M
Max Digging Depth
22.64ft in
Boom/Stick Option (Hex) 1
Boom 19\'2\" (5850mm) / Stick 9\'10\" (2500mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
32.75ft in
I
Max Cutting Height
31.37ft in
C
Shipping Height Of Unit
10.86ft in
J
Max Loading Height
21.49ft in
K
Max Reach Along Ground
31.6ft in
L
Max Vertical Wall Digging Depth
18.71ft in
M
Max Digging Depth
21ft in
Boom/Stick Option (Hex) 2
Boom 19\'2\" (5850mm) / Stick 8\'2\" (2500mm)
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
32.52ft in
I
Max Cutting Height
33.04ft in
J
Max Loading Height
23.17ft in
C
Shipping Height Of Unit
10.86ft in
K
Max Reach Along Ground
34.85ft in
L
Max Vertical Wall Digging Depth
21.92ft in
M
Max Digging Depth
24.35ft in
Boom/Stick Option (Hex) 3
Boom 19\'2\" (5850mm) / Stick 11\'6\" (3520mm)
Dimensions
E
Ground Clearance
1.51ft in
G
Height To Top Of Cab
10.14ft in
B
Width To Outside Of Tracks
11.13ft in
D
Length Of Track On Ground
12.6ft in
H
Tail Swing Radius
9.65ft in
Removal Counterweight Clearance
3.61ft in
Undercarriage
F
Track Gauge
8.5ft in
N
Shoe Size
31.5in
Number Of Track Rollers Per Side
9
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.4mph
Ground Pressure
5.37psi
Number Of Shoes Per Side
51
Specifications
Engine
Number Of Cylinders
4
Engine Make
2353
Engine Model
AH-4HK1X
Net Power
177hp
Power Measured @
2000rpm
Max Torque
469lb ft
Displacement
317.4cu in
Aspiration
Turbocharged
Torque Measured @
1500rpm
Operational
Operating Weight
54895lb
Fuel Capacity
108.4gal
Cooling System Fluid Capacity
6.7gal
Hydraulic System Fluid Capacity
66.1gal
Operating Voltage
24V
Engine Oil Capacity
6.2gal
Swing Drive Fluid Capacity
2.6gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4970psi
Hydraulic Pump Flow Capacity
123.6gal/min
Swing Mechanism
Swing Speed
10.7rpm
Swing Torque
55243lb ft
Buckets
Reference Bucket Capacity
1.7yd3
Minimum Bucket Capacity
0.8yd3
Maximum Bucket Capacity
2.5yd3
