Link-Belt 290LX Log Loader
Units
Dimensions
Boom/Stick Option (Lgl) 1
A
Shipping Length
48.54ft in
C
Shipping Height
11.06ft in
I
Max Height
45ft in
J
Max Reach At Ground Level
39ft in
K
Max Depth Below Ground
14ft in
Boom/Stick Option (Lgl) 1
40\'0\" (12200mm) Loading Boom
Dimensions
B
Overall Width
11.95ft in
D
Length Of Track On Ground
13.19ft in
E
Ground Clearance
2.32ft in
H
Tail Swing Radius
10.44ft in
Undercarriage
F
Track Gauge
9.65ft in
Shoe Size
27.56in
Max Speed
2.5mph
Ground Pressure
8.41psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2353
Engine Model
CC-6BG1TC
Net Power
177hp
Net Torque
443lb ft
Power Measured @
2200rpm
Displacement
396cu in
Torque Measured @
1800rpm
Aspiration
Turbocharged with Intercooler
Operational
Operating Weight
79402lb
Fuel Capacity
89.9gal
Cooling System Fluid Capacity
7.7gal
Engine Oil Capacity
6.4gal
Hydraulic System Fluid Capacity
63.5gal
Operating Voltage
24V
Alternator Supplied Amperage
50amps
Swing Mechanism
Swing Speed
8.1rpm
Swing Torque
81870lb ft
Hydraulic
Pump Type
2x Piston Pumps
Pump Flow Capacity
116.8gal/min
Relief Valve Pressure
4970psi
