Link-Belt ATC822 All Terrain Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
27.14ft in
J
Max Height @ Max Raise Angle - No Jib
70.12ft in
M
Max Elevating Angle
78degrees
Number Of Sections
3
Swing Speed
2rpm
Dimensions
A
Transport Length
32.39ft in
B
Transport Width
8.01ft in
C
Transport Height
10.08ft in
E
Ground Clearance
1.35ft in
F
Width W/ Outriggers Extended
19.89ft in
G
Carrier Length
25.46ft in
H
Upper Structure Tail Swing Radius
11.09ft in
Specifications
Upper Structure Engine
Make
Link-Belt
Carrier Engine
Stroke
4.8in
Bore
4.1in
Make
Link-Belt
Model
ISB 230
Gross Power
230hp
Power Measured @
2500rpm
Max Torque
605lb ft
Torque Measured @
1500rpm
Displacement
359cu in
Number Of Cylinders
6
Operational
Operating Weight
39222.5lb
Carrier Fuel Capacity
40gal
Upper Structure Hydraulic System Fluid Capacity
63gal
Operating Voltage
24V
Alternator Supplied Amperage
130amps
Tire Size
16.0 R 20
Transmission
Transmission Type
ZF full powershift
Number Of Forward Gears
6
Number Of Reverse Gears
3
Max Speed - Forward
55mph
