Link-Belt E30 Articulated Dump Truck
Units
Dimensions
Dimensions
A
Overall Length
32.02ft in
B
Overall Width
9.39ft in
C
Overall Height
11ft in
D
Wheelbase
17.91ft in
E
Ground Clearance
1.59ft in
Dump
Capacity - Struck
17yd3
Capacity - Heaped
21.6yd3
Rated Payload
60000lb
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
M11-C270
Gross Power
270hp
Power Measured @
2100rpm
Max Torque
910lb ft
Torque Measured @
1500rpm
Aspiration
Turbocharged and Aftercooled
Displacement
661cu in
Operational
Fuel Capacity
85.9gal
Hydraulic System Fluid Capacity
52.9gal
Cooling System Fluid Capacity
11.4gal
Engine Oil Capacity
9gal
Transmission Fluid Capacity
5.1gal
Operating Voltage
24V
Alternator Supplied Amperage
70amps
Tire Size
23.5 R25
Transmission
Transmission Type
Power Shift
Number Of Forward Gears
6
Number Of Reverse Gears
3
Max Speed
30mph
Weights
Front Axle - Empty
19841lb
Rear Axle - Empty
19841lb
Total Empty
39682lb
Total Loaded
99208lb
