Manitou MRT 2150 PRIVILEGE PLUS Telescopic Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
22.6ft in
E
Ground Clearance
1.2ft in
B
Width Over Tires
8.2ft in
C
Overall Height
10ft in
D
Wheelbase
10ft in
Turning Radius Outside Tires
17.2ft in
Lift
F
Max Lift Height
68.7ft in
Max Load At Max Reach
58.9lb
Max Lift Capacity
11020.91lb
Specifications
Engine
Emission Tier Level
Tier 4 Final
Number Of Cylinders
4
Engine Model
OM 934 E4-5
Gross Power
156hp
Net Power
154.3hp
Max Torque
497.9lb ft
Torque Measured @
1500rpm
Displacement
19100.5cu in
Injection
Direct
Operational
Hydraulic System Fluid Capacity
59.5gal
Alternator Supplied Amperage
24amps
Drawbar Pull
19558lb
Transmission
Number Of Wheels Front
2
Number Of Wheels Rear
2
Tyre Dimensions Front
445 / 65 R22.5
Tyre Dimensions Rear
445 / 65 R22.5
Driving Position Noise Levels
79.7 dB
Environmental Noise Levels
108 dB
Vibration Affecting Hands/Arms
2.5sec
Max Speed
24.9mph
Transmission Type
Hydrostatic
