Merlo 30.6 Top2 Telescopic Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
16.08ft in
E
Ground Clearance
1.42ft in
B
Width Over Tires
7.39ft in
C
Overall Height
8.19ft in
D
Wheelbase
8.86ft in
Turning Radius Outside Tires
12.8ft in
Lift
F
Max Lift Height
19.69ft in
G
Max Forward Reach
10.34ft in
Max Load At Max Reach
3306.94lb
Max Load At Max Height
6613.87lb
Max Lift Capacity
6613.87lb
Specifications
Engine
Number Of Cylinders
4
Engine Make
2349
Gross Power
114hp
Power Measured @
2400rpm
Aspiration
turbocharged
Operational
Operating Weight
14440.3lb
Fuel Capacity
41gal
Hydraulic System Fluid Capacity
27.8gal
Operating Voltage
12V
Alternator Supplied Amperage
90amps
Tire Size
17.5LR24 14 PR
Transmission
Transmission Type
hydrostatic
Number Of Forward Gears
2
Max Speed - Forward
24.9mph
Hydraulic
Pump Type
twin gear
Pump Flow Capacity
28.3gal/min
Relief Valve Pressure
3045.8psi
