Michigan L270 Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
12.26ft in
Bucket Capacity - Heaped
7yd3
Bucket Capacity - Struck
5.89yd3
Bucket Width
12.34ft in
Breakout Force
80000lb
Dimensions
E
Ground Clearance
1.84ft in
A
Length With Bucket On Ground
33.59ft in
B
Width Over Tires
11.34ft in
C
Height To Top Of Cab
12.84ft in
D
Wheelbase
12.34ft in
F
Hinge Pin - Max Height
16.42ft in
H
Reach At Max Lift And Dump
5.59ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
KT-19-C
Net Power
360hp
Gross Power
400hp
Power Measured @
2100rpm
Max Torque
1349.8lb ft
Displacement
1150cu in
Torque Measured @
1500rpm
Aspiration
turbocharged
Operational
Operating Weight
91070lb
Fuel Capacity
188gal
Hydraulic System Fluid Capacity
120gal
Engine Oil Fluid Capacity
11gal
Cooling System Fluid Capacity
26gal
Transmission Fluid Capacity
19.1gal
Front Axle/Diff Fluid Capacity
16gal
Rear Axle/Diff Fluid Capacity
16gal
Static Tipping Weight
56680.9lb
Turning Radius
28.1ft in
Operating Voltage
24V
Alternator Supplied Amperage
100amps
Rear Axle Oscillation
24degrees
Tire Size
29.5-29 (28 PR) L-4
Transmission
Transmission Type
Clark countershaft type powershift transmission
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed - Forward
21.5mph
Max Speed - Reverse
21.5mph
Hydraulic System
Relief Valve Setting
2750psi
Pump Flow Capacity
179gal/min
Raise Time
8.6sec
Dump Time
3sec
Lower Time
5sec
Pump Type
gear type
