New Holland D85 WT Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
13.69ft in
B
Width Over Tracks
8.5ft in
C
Height To Top Of Cab
9.1ft in
D
Length Of Track On Ground
7.42ft in
E
Ground Clearance
1.25ft in
F
Length W/O Blade
10.35ft in
Undercarriage
G
Track Gauge
5.84ft in
H
Standard Shoe Size
24.02in
Number Of Shoes Per Side
39
Number Of Carrier Rollers Per Side
1
Ground Pressure
4.61psi
Number Of Track Rollers Per Side
6
Track Pitch
6.74in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2249
Engine Model
445T/M2
Gross Power
89hp
Net Power
84hp
Power Measured @
2000rpm
Max Torque
295.1lb ft
Displacement
274.7cu in
Torque Measured @
1400rpm
Aspiration
Natural
Operational
Operating Weight
19700.6lb
Fuel Capacity
50.1gal
Cooling System Fluid Capacity
5gal
Engine Oil Capacity
3.6gal
Hydraulic Fluid Capacity
20gal
Final Drives Fluid Capacity
3.8gal
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Transmission
Transmission Type
Hydrostatic
Number Of Forward Gears
10
Max Speed - Forward
6mph
Hydraulic System
Pump Type
Gear
Pump Flow Capacity
20.3gal/min
Standard Blade
Width
9.2ft in
Height
35.9in
Capacity
2.4yd3
Blade Angle (Both Directions)
25degrees
Cutting Depth
19.1in
