New Holland D95B LGP Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
13.97ft in
B
Width Over Tracks
9.99ft in
C
Height To Top Of Cab
9.15ft in
D
Length Of Track On Ground
7.72ft in
E
Ground Clearance
1.22ft in
F
Length W/O Blade
10.71ft in
Undercarriage
G
Track Gauge
5.84ft in
H
Standard Shoe Size
27.96in
Number Of Shoes Per Side
40
Number Of Carrier Rollers Per Side
7
Ground Pressure
4psi
Number Of Track Rollers Per Side
1
Track Pitch
6.74in
Specifications
Engine
Number Of Cylinders
4
Engine Model
FPT 445TA/E66
Gross Power
99hp
Net Power
96hp
Power Measured @
2200rpm
Max Torque
295lb ft
Displacement
275cu in
Torque Measured @
1400rpm
Operational
Operating Weight
20721.3lb
Fuel Capacity
50gal
Cooling System Fluid Capacity
6gal
Engine Oil Capacity
3.3gal
Hydraulic Fluid Capacity
20gal
Final Drives Fluid Capacity
3.8gal
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Transmission
Transmission Type
Hydrostatic
Number Of Forward Gears
10
Number Of Reverse Gears
10
Max Speed - Forward
5.5mph
Max Speed - Reverse
5.5mph
Hydraulic System
Pump Type
Geaar
Pump Flow Capacity
20.3gal/min
Standard Blade
Width
10.9ft in
Height
35.9in
Capacity
2.8yd3
Blade Angle (Both Directions)
25degrees
Cutting Depth
19.1in
